Product Highlights
| Zero Ozone Depletion Potential (ODP) | Comply with RoHS Environmental Directive | Comply with REACH Environmental Directive |
| High Cleaning Performance | Suitable for Various Cleaning Processes | No Residue |
| Wide Range of Material Compatibility | Low Volatile Organic Compounds (VOC) | Safety |
Product Features?
It has good decontamination ability and fast cleaning speed, and is an ideal cleaning agent for the electronics industry.
It has low surface tension, strong penetration and fast cleaning speed.
It is easy to operate and non-corrosive.
It dries quickly after cleaning and has good surface cleanliness.
It does not produce toxic and harmful substances and is a green and environmentally friendly product.
Scope of application?
This product is suitable for cleaning PCBA after soldering and cleaning SMT printing nets. It can also be used to clean PCB boards with misprinted solder paste and glue. It has no corrosive effect on metal and plastic products. It can be used in a variety of cleaning processes such as ultrasonic, spraying, and manual.
Physical and Chemical Parameters?
Item | Parameters? |
Appearance | Colorless Transparent Liquid |
Specific Gravity (g/cm 3 @20℃) | 0.800±0.020? |
Boiling Range(℃) | ≤130.0 (Final boiling point) |
ODS Substances | PASS |
RoHS Directive Substances | PASS |
Halogen（ppm） | PASS |
| REACH Directive Substances | PASS |
Storage Temperature（℃） | 5.0～35.0 |
Instructions for use
Ultrasonic cleaning:?Adjust the vibration frequency of the ultrasonic wave and control the appropriate cleaning temperature to make the cleaning agent reach the best cleaning state. The parts to be cleaned should be completely immersed in the cleaning agent and placed at an appropriate spacing.
Spray cleaning:?Adjust the flow rate of the cleaning agent, the spray pressure, and control the appropriate cleaning temperature to make the cleaning agent reach the best cleaning state. The parts to be cleaned should pass through the best atomization area.
Manual cleaning:?Use an anti-static brush, dust-free cloth, or toothbrush to dip the cleaning agent on the surface of the parts to be cleaned, and brush repeatedly to remove the dissolved dirt from the parts to be cleaned.
Soaking cleaning:?Place the cleaning agent in a suitable container and the parts to be cleaned should be completely immersed in the cleaning agent.
Replacement frequency: After a period of use, the residue in the cleaning agent will increase, causing the cleaning force to decrease, and the cleanliness of the parts after washing will deteriorate. The cleaning agent in the tank needs to be added and replaced regularly (depending on the number of parts to be cleaned).
Cleaning time:?5 to 30 minutes is recommended, depending on the specific cleaning process and cleanliness requirements.
Please Note
- After opening the product and taking out the used part, the lid must be closed tightly to prevent the cleaning agent from volatilizing.
- Do not put used cleaning agents and unused cleaning agents in the same packaging barrel. After the cleaning agent is opened, if there is still cleaning agent left in the barrel, it cannot be left open to the air, and the lid should be tightened as soon as possible.
- The container containing the cleaning agent should be kept clean to prevent dirt and other substances from mixing into the cleaning agent and affecting the quality of the cleaning agent.
- Before use, the solubility compatibility with printed screens and plastic materials and related components should be tested.
- The cleaning agent is volatile, and ventilation should be ensured at the work site.
- For safety precautions, please refer to the MSDS of this product.
Packing Specifications?
20L、50L
Storage and Transportation Requirements
Keep it sealed and away from direct sunlight and high heat.
Warranty period is 12 months in sealed state.
